5020

5020 Product is a gland packing which carbon fiber is treated with PTFE dispersion and special lubricant and then braided into a cross-sectionally square shape.
Excellent compatibility with shafts Excellent in sealing properties at low fastening Chemical resistance can be used for a wide range of fluids.

Specification

Heatproof temperature 260 ℃
Pressure resistance 2.0 MPa
Peripheral velocity 10 m / s
PV value 14.7 MPa · m / s
pH value 0-14
Applied fluid Clear seawater, slurry liquid, heated water, boiler feed water, animal and vegetable oils, thermal oil, crude oil, heavy oil, weak acid, weak alkali, strong alkali, slurry, polymer, low temperature liquefied fluid, hot air, exhaust gas etc.
Standard dimensions 3.0 mm □ ~ 25.0 ㎜ □
Standard length 3 mL / Case
Notes Please contact us for details.

Additional information

Application

Pump
stirrer
Various rotary equipment
valves (adapter packing)

Specialty

It
can be used under high circumferential speed conditions with less shaft wear.
Excellent in chemical resistance Excellent
sealing properties Excellent compatibility with
shafts Excellent
elasticity Excellent
handling
