9320 CleaHybrid

CleaHybrid is a high performance rubber sheet gasket integrating rubber sheet technology based on gasket design philosophy.
Excellent in heat resistance, stress relaxation, compression restorability, electrical insulation and weather resistance We have the ability to overturn the common sense of existing rubber type sheets.

SKU: 9320 CleaHybrid Category: Tags: , , , ,

Description

Specification

Heatproof temperature -47 to 150 ° C
Pressure limit 3.0 MPa
Thickness 1.5 mm, 2.0 mm, 3.0 mm, 4.0 mm, 5.0 mm
Sheet size 1250
mm W * 5000 mm L (1.5 mm, 2.0 mm, 3.0 mm ) 1000 mm W * 2000 mm L (4.0 mm, 5.0 mm)
Material EPDM
Allowable surface pressure 10 MPa
Notes Please do not use gasket paste.
Please contact us for applicable fluids.

Additional information

Application

Seawater flange
General piping, flange
Various equipment gaskets
Specialty

Excellent weather resistance Excellent
sealability Excellent
versatility Low
stress relaxation (reduction of surface pressure)
Excellent electrical insulating properties Excellent
compression recovery properties
